DAB Esybox Mini 3 Electronic Pressurization System
Product Overview
The DAB Esybox Mini 3 is an automatic water-pressure booster system with variable-frequency-drive technology. It adjusts pump operation to system demand to help maintain steady pressure for compatible domestic water, potable-water, and garden-water applications.
Key Features:
- Electronic pressurization and booster system
- Variable-frequency-drive operation
- Automatic pressure control based on water demand
- High-resolution LCD interface
- Integrated 1/4 gal. expansion vessel and cartridge check valve
- Supports fixed horizontal or vertical installation
- DConnect remote-control support
Common Uses:
- Boosting household water pressure
- Compatible potable-water supply systems
- Garden and irrigation water-pressure support
- Applications requiring automatic constant-pressure operation
Technical Specifications:
- Model / SKU: 60212610
- Maximum Flow: Up to 22 GPM
- Maximum Head: Up to 183 ft
- Maximum Suction Depth: 26 ft
- Maximum Settable Pressure: 79 PSI
- Expansion Vessel: Integrated 1/4 gal.
Approvals:
- CSA
- UL
- NSF/ANSI 61
- NSF/ANSI 372
Installation and Sizing Notes:
Confirm the required flow, pressure, suction conditions, pipe sizing, electrical supply, and installation orientation before ordering. Pump selection should be based on the complete system requirements rather than maximum ratings alone. Installation should be completed by qualified plumbing and electrical professionals in accordance with the manufacturer instructions and applicable requirements.
FAQ:
What does the Esybox Mini 3 do?
It automatically boosts water pressure and varies pump speed to match system demand.
Can it be installed horizontally or vertically?
Yes, the system supports fixed horizontal or vertical installation.
What is the maximum settable pressure?
The maximum settable pressure is 79 PSI.
Is pump sizing based only on the 22 GPM maximum flow?
No. Required pressure, head, suction conditions, piping, and actual demand must also be evaluated.
