Product Overview

The DIG 18-008 adjustable regulator reduces higher inlet pressure to a selected downstream pressure from 12 to 35 PSI for compatible drip-irrigation and micro-sprinkler systems. Its white color code identifies this adjustment range.

Key Features:

• Adjustable 12-35 PSI downstream range
• White color-coded model
• 3/4 in. FNPT connection
• Rolling-diaphragm design
• Glass-filled nylon body and actuator
• Can be installed in multiple orientations as permitted by the system layout

Common Uses:

• Regulating low-pressure drip-irrigation zones
• Supplying compatible micro-sprinkler systems
• Applications requiring adjustable downstream pressure

Technical Specifications:

• Adjustment Range: 12-35 PSI
• Flow Range: 0.88-22 GPM
• Maximum Working Pressure: 125 PSI
• Connection: 3/4 in. FNPT
• Maximum Water Temperature: 122°F
• Weight: 0.75 lb
• Body and Actuator: Glass-filled nylon
• Diaphragm: Fabric-reinforced Buna-N
• Spring: 304 stainless steel

Installation and Use Notes:

Install in the direction of flow and downstream of the appropriate control valve. Adjust pressure while water is flowing within the stated range, then verify downstream pressure with a gauge.

FAQ:

Is this regulator preset?
No. It adjusts from 12 to 35 PSI.

What connection does it use?
It uses a 3/4 in. female pipe-thread connection.
