Stiebel Eltron Tempra 15 Trend Tankless Water Heater 239214
Stiebel Eltron Tempra 15 Trend Tankless Water Heater 239214
Product Overview
The Stiebel Eltron Tempra 15 Trend is an advanced whole-house electric tankless water heater designed to supply continuous hot water on demand. Operating at a notable 0.96 Uniform Energy Factor (UEF) and 97% recovery efficiency, this unit activates only during hot water usage, eliminating the standby thermal loss common with traditional storage tank models. Built with precision German engineering and high-quality parts, it stands out as an exceptionally reliable and energy-efficient solution for updating residential hot water delivery.
As a key component of the Trend series, this system manages hot water demands within a compact, wall-mounted enclosure that helps save physical floor space. Its durable construction meets strict plumbing regulations, and it is capable of handling incoming water temperatures up to 131°F. This makes the unit remarkably versatile, allowing it to function effectively as either a standalone water heater for compact homes or as an inline temperature booster for pre-heated systems.
Key Features:
- On-Demand Heating Efficiency: Achieves a 0.96 UEF rating by heating water instantly at the point of use, effectively lowering utility costs and wasting less energy.
- Space-Saving Wall Mount: Compact dimensions eliminate the need for bulky water storage tanks, allowing for cleaner installations in closets and utility areas.
- High-Temperature Input Safety: Accommodates maximum inlet water temperatures up to 131°F (55°C) to easily support commercial or pre-heated inline setups.
- Certified Lead-Free Build: Evaluated and certified to ensure strict material safety and dependable code compliance for residential drinking water.
Technical Specifications:
- Voltage: 240 V or 208 V
- Phase: Single 50/60 Hz (Can be wired for unbalanced 3-phase 208V)
- Wattage: 14.4 kW (at 240V) / 10.8 kW (at 208V)
- Amperage Draw: 2 x 30 A (at 240V) / 2 x 26 A (at 208V)
- Minimum Recommended Circuit Breakers: 2 x 30 A (DP)
- Number of Runs & Minimum Wire Size: 2 x 10/2 AWG Copper
- Dimensions: 16-5/8" W x 14-1/2" H x 4-5/8" D
- Weight: 16.1 lb (7.3 kg)
- Nominal Water Volume: 0.26 gal (1.0 L)
- Water Connections: 3/4" NPT
- Working / Tested Pressure: 150 psi (10 bar) / 300 psi (20 bar)
- Uniform Energy Factor (UEF) / Recovery Efficiency: 0.96 / 97%
- Certifications: Tested and certified by WQA against NSF/ANSI/CAN 372 for lead-free compliance; Conforms to UL Std. 499; Certified to CAN/CSA Std. C22.2 No.88
Installation & Versatility:
- Main Service Requirements: Requires a minimum main service electrical panel rating of 100 A to safely support the full electrical load.
- Low Flow Activation: Successfully triggers heating elements at a minimum water flow rate of 0.50 GPM (1.9 L/min) to accommodate modern low-flow plumbing fixtures.
- Standardized Piping Connections: Outfitted with 3/4" NPT fittings to ensure straightforward plumbing integration with standard copper lines.
- Pressure Tolerances: Designed to function smoothly at a minimum operational pressure of 30 psi and rated to manage working pressures up to 150 psi.
Common Applications:
- Small to Medium Residences: Serves as a space-saving whole-house water heating solution for apartments, condos, and small single-family homes.
- Long Pipe Run Temperature Boosting: Installs perfectly down-line from a centralized water heater to restore and maintain proper temperatures over long pipe distances.
- Vacation Cabins and Properties: Offers instant hot water upon arrival and can be completely turned off when the property is vacant to prevent unnecessary power usage.
Frequently Asked Questions:
- Q: What is the maximum temperature rise this unit can provide at a flow rate of 1.50 GPM?
- A: At a flow rate of 1.50 GPM, the Tempra 15 Trend provides a maximum temperature rise of 65°F when powered by 240V, and a 49°F rise when operating on 208V.
- Q: What size electrical wire and breakers are necessary for installation?
- A: The installation requires two dedicated runs of 10/2 AWG copper wire and two 30 A double-pole (DP) circuit breakers.
- Q: Is this water heater safe for drinking water lines?
- A: Yes, it is fully tested and certified by the WQA against NSF/ANSI/CAN 372 for strict lead-free compliance.
The Stiebel Eltron Tempra 15 Trend is an exceptionally compact and energy-efficient tankless water heater, making it an ideal choice for contractors and homeowners looking to upgrade their hot water infrastructure.
