Product Overview

The DIG MP-125 is a low-flow pop-up micro sprayer with a 180-degree pattern, 1/4 in. barbed inlet, and 9 in. pop-up height.

Key Features:

• 180-degree spray pattern
• 9 in. pop-up riser
• 1/4 in. barbed inlet
• Stainless steel spring
• EPDM and vinyl seals
• Designed for low-flow overhead irrigation

Common Uses:

• Edges of flower beds and groundcover
• Plantings beside walls or walkways
• Areas needing a retracting micro-spray riser

Technical Specifications:

• Flow Range: 0.15-0.63 GPM
• Operating Pressure: 15-30 PSI
• Nominal Pressure: 30 PSI
• Maximum Wetting Diameter: 11.2 ft
• Filter Requirement: Minimum 80 mesh
• Pattern: 180 degrees

Dimensions:

• Pop-Up Height: 9 in.
• Inlet: 1/4 in. barb

Installation Notes:

Connect to compatible micro tubing, use regulated and filtered water, and orient the half-circle pattern along the planting edge. Flush the line before installation.

FAQ:

What pattern does it provide?
180 degrees.

How high does it pop up?
9 in.
